6 Size Channels: Standard: 0.3, 0.5, 0.7, 1.0, 2.0, 5.0 µm
IAQ: 0.5, 0.7, 1.0, 2.0, 5.0, 10.0 µm
Custom: 0.3 to 20 µm available
Flow Rate: 0.1 cfm (2.83 L/min)
Light Source: Laser diode; index guided (26,000 MTBF at 25°C)
Calibration: PSL particles in air (NIST traceable)
Counting Efficiency: 50% @ 0.3 µm; 100% for particles > 0.45 µm (per JIS B9921:1997)
Zero Count: 1 count/5 minute (per JIS B9921:1997)
Coincidence Loss: 5% at 2,000,000 particles per ft3
Relative Humidity: ± 7%, 20% to 90%, non-condensing
Temperature: ± 3°C, 10°C to 40°C (50°F to 104°F)
Data Storage: 500 sample records (rotating buffer)
Data Recorded: Date, time, counts, relative humidity, temperature,
sample volumes, alarms, label
Display: Graphic liquid crystal with back light
Alarms: Counts, low battery, sensor fail
Count Modes: Concentration, totalize, audio
Delay Time: 0 to 24 hours
Sample Inlet: Isokinetic probe
Interface: RS-232 and RS-485 via RJ-45
Vacuum Source: Internal pump flow controlled
Housing: Injection molded plastic
Dimensions: 4.5" w x 8.25" l x 2.25" d (11.43 x 20.96 x 5.72 cm)
Weight: 2.2 pounds (1.0 kg)
Environmental: Operating: 10°C to 40°C (50°F to 104°F),
20% to 90% relative humidity, non-condensing
Storage: -10°C to 50°C (14°F to 122°F),
Up to 90% relative humidity, non-condensing
Power: AC Adapter, 12 VDC at 2.5 A, 90 to 250 VAC, 50 to 60 Hz
Rechargeable Battery: NiMH, 4.8 V at 4.5 Ah; replaceable
Continuous Operating Time: 8 hours
Recharge Time: 2 hours
Standards: CE, JIS B9921: 1997
Accessories Included: Certificate of Calibration (NIST); Windows compatible software
download utility; DB9 to RS-232 adapter and cable;
Isokinetic Probe; High Purity Tubing; 1/8 in. Hose Barb Adapter;
Power Supply; Operation Manual
Zero Count Filter
Carrying Case (soft-sided or hard molded plastic) data
Portable serial printer w/cable, 2 rolls paper
Option “EX” – 2,000 records
Optional particle size range – up to 20 µm
Specifications are at reference conditions and may change without notice. All trademarks are property of their respective owners. PN705125–04/03
SPECIFICATIONS
OPTIONAL
ACCESSORIES
Model HHPC-6 Handheld Particle Counters
