PARAMETRY TECHNICZNE
COMMON DATA (ALL MODELS)
GENERAL
Source impedance Zi = <10mohm
Voltage deviation <1V with resistive load (including
inrush current) recovering 63% of its
maximum excursion within 100us
Ripple voltage Ur <0.2Vp-p, frequency min. 400Hz
Sinusoidal signal
capability vs.
Frequency *) Vpp max. 16V up to 20kHz
Vpp max. 10V up to 30kHz
Vpp max. 6V up to 50kHz
*) Vpp max. 3V up to 100kHz via
Analog In, controlled by
AutoWave/AMP 200Nx only
*) VDS 200N30.1 and VDS 200N50.1:
Vpp max. 65V resp. 35V up to 50kHz
with respect to the selected voltage
range
Vpp max. 3V up to 100kHz via
Analog In, controlled by
AutoWave/AMP 200Nx only
Fuses Depending on VDS 200N model
TRIGGER
Automatic Automatic release of the events
Manual Manual release of a single pulse
External External release of a single pulse
OUTPUT
DUT Supply +/- Safety laboratory or high current
connectors
Ext. trigger 5-15V TTL; BNC connector
CRO Trigger 5V TTL-signal for oscilloscope
COMMON DATA (ALL MODELS)
TEST ROUTINES FOR ARBITRARY WAVES
DC source Max. 60V; current depending
on VDS 200N model
Functions Sine Wave Sweep
Sine Wave (Cranking)
Clipped Load Dump
Jump Start
Extern
GM 9105P Pulse 4
Drop and Jump pulse
Standard Test
routines ISO 7637, Pulses 2b and 4
ISO 16750-2
Jaso Test 1
Service Service, Setup, Self test
INTERFACE
Serial interfaxe USB
Parallel interface IEEE 488, addresses 1 - 30
Remote control To connect an external signal
generator (10kohm):
0-10V / 0-50kHz
max. 0.5V(p-p) / 0-100kHz
OPTIONS
AutoWave Arbitrary generator for more complex
test requirements
iso.control Software to control the test,
including standard library, test
report facility and data conversion
generator
