DATA SHEET > LD 200N > 20081103
TECHNICAL DETAILS
FREESTYLE MODE LOAD DUMP
PULSE PROGRAMMING MODE
Rise time <1us
10us - 90us with 10us steps
100us - 900us with 100us steps
1ms - 10ms with 1ms steps
Pulse duration 10ms - 1,200ms
Int. resistor 0.5ohm - 38ohm, in steps of 0.1ohm
MODULE CLIPPED LOAD DUMP
TEST ROUTINES (REQUIRES OPTIONAL CLD MODULE)
Standard Test
routines pre-programmed and controlled via
iso.control
ISO 7637-2 Pulse 5b for 12V and 24V
ISO/WD 16750 Pulse 5b
SAE J1113-11 Pulse 5b
FIAT 9.90110 Pulse 5a
PSA B21 7110 Pulse 5b for 12V
Volvo Pulse 5a and 5c
GS 95003-2 Pulse 5b
Porsche EMV Pulse 5
GMW 3097 Pulse 5b
36.00.808/--H Pulse 5b
TSC 7034G Pulse 5b
Iveco Pulse 5b
Scania TB1400 Pulse 5b
Scania TB1700 Pulse 5b
ES 96100-02 Pulse 5b
PULSE PROGRAMMING MODE (REQUIRES OPTIONAL CLD
MODULE)
Clipped Voltage 15V - 95.5V, in steps of 0.5V
Rise time 100us - 10ms
Pulse duration 10ms - 1,200ms
Int. resistor 0.5ohm - 38ohm, in steps of 0.1ohm
GENERAL DATA
DIMENSIONS AND WEIGHT
Dimensions 19"/6HU, 500mm x 450mm x
290mm
Weight approx. 25kg
Supply voltage 115V/230V +10%/-15%
Fuses 2x T2AT (230V) or 2x T4AT (115V)
OUTPUT
+/- output Safety laboratory connectors
Coupling To the battery +line
Decoupling Via diode
DUT supply Max. 60V/30A
INTERFACE
Serial interface USB
Parallel interface IEEE 488, addresses 1 - 30
CN interface To control external CN - UCS 200N
OPTIONS
iso.control Software to control the test,
including standard library, test
report facility and data conversion
generator
www.emtest.com © EM TEST > PAGE 4/5
