Input Specifications
Voltage 115/230 VAC ± 10%, user selectable
Frequency 50/60 Hz ± 5%
Fuse - 3130 6.3 A, slo-blow 250 VAC
Fuse - 3140 10 A, slo-blow 250 VAC
Fuse - 3130 15 A, slo-blow 250 VAC
Ground Bond Test Mode
Output Rating Current 3130: 1.00 - 30.00 A AC
Voltage 3130: 6 V AC, fixed
Current 3140: 1.00 - 40.00 A AC
Voltage 3140: 8 V AC, fixed
Current 3160: 1.00 - 60.00 A AC
Voltage 3160: 9 V AC, fixed
Resolution: 0.01 A
Regulation: ± (2% of setting + 0.02 A)
Output Frequency Range: 50 / 60 HZ, User Selectable
Dwell Time Setting Range: 0 and 0.5 - 999.9 secs
0 for continuous running
Resolution: 0.1 sec
Accuracy: ± (0.1% of setting + 0.05 secs)
Maximum & Minimum Range 3130: 0 - 120 m Ω for 1 - 30.00 A
Limits 0 - 510 m Ω for 1 - 10.00 A
Accuracy 3130: ± (2% of setting + 2 m Ω)
Range 3140: 0 - 150 m Ω for 30.01 - 40.00 A
0 - 200 m Ω for 10.01 - 30.00 A
0 - 600 m Ω for 1.00 - 10.00 A
Accuracy 3140: ± (3% of setting + 3 m Ω)
Range 3160: 0 - 150 m Ω for 30.01 - 60.00 A
0 - 300 m Ω for 15.01 - 30.00 A
0 - 600 m Ω for 6.00 - 15.00 A
Accuracy: ± (3% of setting + 3 m Ω)
Offset Capability Range: 0 - 100 m Ω
Resolution: 1 m Ω
Accuracy: ± (2% of setting + 2 m Ω)
Current Display 3130 Range: 0.00 - 30.00 A
Resolution: 0.01 A / step
Accuracy: ± (2% of reading + 0.02 A)
Current Display 3140 Range: 0.00 - 40.00 A
Resolution: 0.01 A
Accuracy: ± (3% of reading + 0.03 A)
Current Display 3160 Range: 0.00 - 60.00 A
Resolution: 0.01 A
Accuracy: ± (3% of reading + 0.03 A)
Ohmmeter Display 3130 Range: 0 - 510 m Ω
Resolution: 1 m Ω / step
Accuracy: ± (2% of reading + 0.02 A)
Ohmmeter Display 3140 Range: 0 - 150 m Ω for 30.01 - 40.00 A
0 - 200 m Ω for 10.01 - 30.00 A
0 - 600 m Ω for 6.00 - 10.00 A
Resolution: 1 m Ω
Accuracy: ± (2% of reading + 2 m Ω)
Range: 0 - 600 m Ω for 1.00 - 5.99 A
Resolution: 1 m Ω
Accuracy: ± (3% of reading + 3 m Ω)
Ground Bond Test Mode (Continued)
Ohmmeter Display 3160 Range: 0 - 150 m Ω for 30.01 - 60.00 A
0 - 300 m Ω for 15.01 - 30.00 A
0 - 600 m Ω for 6.00 - 15.00 A
Resolution: 1 m Ω
Accuracy: ± (2% of reading + 2 m Ω)
Range: 0 - 600 m Ω for 1.00 - 5.99 A
Resolution: 1 m Ω
Accuracy: ± (3% of reading + 3 m Ω)
Timer Display Range: 0.0 - 999.9 secs
Resolution: 0.1 secs
Accuracy: ± (0.1% of reading + 0.05 secs)
General Specifications
Remote Control & The following input and output signals are provided
Signal Output through two 9 pin D type connectors:
1. Remote control: Test, Reset, Interlock, and
Withstand Processing
2. Remote recall of memor y program #1, #2, and #3
3. Outputs: Pass, Fail, Test-in-process, Start Out
and Reset Out
Program Memory 10 Memories, 3 steps per memor y.
Security Key Lock capability to avoid unauthorized access to
all test parameters and memor y locations.
Mechanical Bench or rack mount with tilt up feet.
Dimensions 3130 (W x H x D) 8.5 x 4.0 x 15.5 in. (216 x 103 x 390 mm)
includes feet
Dimensions 3140 (W x H x D) 8.5 x 4.0 x 16.9 in. (216 x 103 x 430 mm)
includes feet
Dimensions 3160 (W x H x D) 16.9 x 5.1 x 15.7 in. (430 x 130 x 400 mm)
includes feet
Weight 3130 19.15 lbs (8.7 kgs)
Weight 3140 30.9 lbs (14 kgs)
Weight 3160 49.40 lbs (22.40 kgs)
Calibration Traceable to National Institute of Standards &
Technology (NIST). Calibration controlled by software.
Adjustments are made through front panel keypad in
a restricted access calibration mode. Calibration
information stored in non-volatile memor y.
Available Accessories
Probe (38084) Fixed tip 4-wire Ground Bond probe for use with the 3130.
Probe (38538) Fixed tip 4-wire Ground Bond probe for use with the 3140.
