SPECIFICATIONS
Sensitivity......................................................................0.4–1000 V/m (probe dependent)
12.0 mA/m–17 A/m (probe dependent)
Frequency response ......................................................100 kHz - 60 GHz (probe dependent)
Inputs ...........................................................................Up to 4 independent probes, through 4 F/O FSMA pairs
Overload withstand.......................................................Probe dependent
Output .........................................................................graphical, color LCD digital display, resolution 0.01
IEEE-488
interface
USB 2.0 (test and measurement class)
RS-232 interface
Ethernet
Sample Rate .................................................................1-60 Samples/sec. (probe dependent)
Power requirements
Input voltage..........................................................Universal input 90 - 260 VAC, 50-60 Hz
Input current ..........................................................0.2 - 0.6 Amps
Input type ..............................................................IEC Inlet with filter
Fuse ......................................................................1A, 5x20 mm slow blow
Operating temperature range........................................10 - 40° C (50 - 104° F) @ 5 - 95% RH non-condensing
Enclosure......................................................................Desktop case, 2U high
Correction factor tables
Number of tables ...................................................Stores up to 6 different tables (each table corresponding to one probe)
Frequency points per table......................................2 to 30
Weight
without enclosure ...................................................2.3 kg (5 lb)
with enclosure ........................................................6.7 kg (14.75 lb)
Size (WxHxD)
without enclosure ...................................................48.3 x 9.0 x 25.4 cm (9 x 3.5 x 10 in)
with enclosure ........................................................49.8 x 12.7 x 30.5 cm (19.6 x 5.0 x 12.0 in)
MODEL DESCRIPTION
FM7004 Housed in a 2U instrument case
FM7004M1 Rack mount (Instrument case removed)
FM7004M2 Housed in a 3U instrument case to allow for one FI7000 to be installed
FM7004M3 Housed in a 4U instrument case to allow for two FI7000’s to be installed
FM7004M4 Housed in a 6U instrument case to allow for four FI7000’s to be installed
