Atec Alber-CRT400 - Manual (Page 2)

System Measurements Display
•
Type: LCD - STN Reflective
•
Viewing Area: 2.619” x 1.309”
•
Resolution: Graphics LCD 128 x 64
•
Viewing Angle: 40˚
•
Backlight: White LED
Memory
•
Type: USB Flash Drive
•
Storage Capability: 1MB per 71 strings with
256 cells
•
Data Retention: 10 Years
Communications
•
Infrared: PC interface for data transfer;
Physical IrDA compliant for printer interface
Battery
•
Type: 4 cell - 8800 mAh lithium ion
•
Voltage: 4.2V
•
Charge Time: 8 hrs
AC Adapter
•
Input Voltage: 90 - 264VAC
•
Output Voltage: 5VDC
•
Output Current: 4.0 Amps
•
Frequency: 47 - 63HZ
Environmental
•
Operating Temp: 0˚C - 40˚C (32˚F - 104˚F)
•
Storage Temp: -29˚C - 60˚C (-20˚F - 140˚F);
For extended periods <25˚C (<77˚F)
•
Humidity Range: 0% to 80% RH (non-
condensing) at 0˚C - 31˚C; 0% to 50% RH
(non-condensing) at 32˚C - 40˚C
•
Insulation Category II
•
Pollution Degree 2
•
Altitude: 0 to 2000 meters above sea level
Packaging
•
305mm (12”)H x 178mm (7”)W x 76mm (3”)D
•
Weight: 1.5Kg (3.4lbs)
•
Keypad: Rubber keys with polyurethane
coating
Warranty
•
Type: 1-year limited warranty
Ordering Information
•
1000-056: Cellcorder including software, carrying
case, USB Flash drive, battery charger, cables,
test and voltage leads.
Optional Accessories
•
2027-014: CRT BAS Software
•
2025-124: Printer with IRDA interface
•
2023-036: Bluetooth ® Earpiece
•
2030-005: USB Flash Drive
•
Various: Spike Probe Options
Specifications subject to change without notice.
CRT-400 - Cellcorder
TM
System Specifications
3103 N. Andrews Ave. Extension • Pompano Beach, FL 33064
Phone: 800.851.4632 • Fax: 954.623.6671 • Internet: www.alber.com • email: [email protected]
Input
Test
Current
Resistance
Resolution
± 0.1% of
reading
Voltage
Resolution
Intercell
Range/
Resolution
2V 50A ± 5μΩ 0.1% - ± 1mV 2mΩ± 2μΩ
4-6V 25-30A ± 25μΩ 0.1% - ± 3mV 3.3mΩ± 5μΩ
8-12V 30-35A ± 75μΩ 0.1% - ± 6mV 5mΩ± 10μΩ
16V 5A ± 400μΩ 0.1% - ± 10mV 20mΩ± 20μΩ
178mm (7”) 76mm (3”)
305mm (12”)
