5- and 1-kV
Megohmmeters
Item (Qty) Cat. No.
5 kV Megohmmeter 210400
15 kV Megohmmeter 210415
Included Accessories
Ground connection cable, 10 ft [3 m] 4702
Test record card, universal 210954
Power cord, for Cat. No. 210415 17032
Instruction manual for 5-kV model AVTM21-40JA
Instruction manual for 15-kV model AVTM21-415JA
ORDERING INFORMATION
5-kV Model, Cat. No. 210400
Input Voltage
120 Vac, 60 Hz
Test Voltage
0 to 5 kVdc, negative with respect to ground
Output Current
5 mA continuous
Short-Circuit Current
12 mA max.
Instrumentation
Kilovoltmeter: 4.5-in. (114-mm) taut band
Three Color-Coded Scales
Red: 0 to 2.5 kV
Black: 0 to 5 kV
Green: 0 to 1 reference
Accuracy: ±2% full scale
Megohmmeter
4.5-in. (114-mm) taut band
Two Color-Coded Scales
Red: 0.5 to 50 M
Ω
Black: 1 to 100 M
Ω
Accuracy: ±0.031 in. (0.08 cm) at any marking
Operating Temperature Range
0 to 122º F (–17.7 to +50º C)
15-kV Model, Cat. No. 210415
Input Voltage
120 Vac, 60 Hz
Test Voltage
0 to 15 kVdc, negative with respect to ground
Output Current
2 mA continuous (stabilizer out)
50 µA continuous (at 15 kV, stabilizer in)
Short-Circuit Current
12 mA max.
Instrumentation
Kilovoltmeter: 4.5-in. (114-mm) taut band
Three Color-Coded Scales
Red: 0 to 7.5 kV
Black: 0 to 15 kV
Green: 0 to 1.5 reference
Accuracy: ±2% full scale
Megohmmeter
4.5-in. (114-mm) taut band
Two Color-Coded Scales
Red: 1 to 100 M Ω
Black: 2 to 200 M
Ω
Accuracy: ±0.031 in. (0.08 cm) at any marking
Operating Temperature Range
0 to 122º F (–17.7 to +50º C)
DC Test Megohm Range Multiplier
Cat. No. Model Voltage x1 x10 x100 x1000 Dimensions Weight
2.5 kV dc 0.5 to 50 5 to 500 50 to 5000 500 to 50,000 10 H x 10.2 W x 14 D in. 20.5 lb
210400 5-kV 5 kV dc 1 to 100 10 to 1000 100 to 10,000 1000 to 100,000 254 H x 260 W x 355 D mm 9.3 kg
250 V to 5 kV Multiply M
Ω
by factor indicated in green
7.5 kV dc 1.5 to 150 15 to 1500 150 to 15,000 1500 to 150,000 12.5 H x 11.5 W x 20.2 D in. 35 lb
210415 15-kV 15 kV dc 3 to 300 30 to 3000 300 to 30,000 3000 to 300,000 317 H x 292 W x 514 D mm 15.9 kg
500 V to 15 kV Actual kV
10
x Range at 10 kV
SPECIFICATIONS
Item (Qty) Cat. No.
Optional Accessories
Test record card, 0 to 1000 G
Ω
210959
Test report sheet for rotating equipment 210951-1
Test report sheet for power transformers 210951-2
Test report sheet for power cables 210951-3
Bushing guard spring 217003
“Lowdown on HV DC Testing” manual AVTM22P-1
“A Stitch in Time” manual AVTM21-P8B
UK
Archcliffe Road Dover
CT17 9EN England
T +44 (0) 1304 502101
F +44 (0) 1304 207342
UNITED STATES
4271 Bronze Way
Dallas TX75237-1088 USA
T 800 723 2861 (USA only)
T +1 214 330 3203
F +1 214 337 3038
OTHER TECHNICAL SALES OFFICES
Valley Forge USA, Toronto CANADA,
Mumbai INDIA, Trappes FRANCE,
Sydney AUSTRALIA, Madrid SPAIN
and the Kingdom of BAHRAIN.
Registered to ISO 9001:2000 Reg no. Q 09290
Registered to ISO 14001 Reg no. EMS 61597
MEGOHMMETERS_DS_en_V10
