Input Specifications
Voltage 115 / 230 V selectable, ± 10% variation
Frequency 50/60 Hz ± 5%
Fuse 115 VAC, 230 VAC - 6.3 A Slow-Blo 250 VAC
Dielectric Withstand Test Mode
Output Rating 5 KV @ 40 mA AC
5 KV @ 20 mA DC
50/60 Hz user selectable
HI and LO-Limit/ AC Total Range: 0.000 mA - 40.00 mA
Current Display AC Real Range: 0.000 mA - 40.00 mA
DC Range: 0.0 - 20,000 µA
Ramp HI >20 mA peak maximum, ON/OFF selectable
Charge LO Range: 0.000 - 350 µA or Auto Set
DC Output Ripple ≤ 4% Ripple RMS at 5 KV DC @ 20 mA, Resistive Load
Discharge Time ≤ 200 ms
Maximum 1 µF < 1 KV 0.08 µF < 4 KV
Capacitive Load 0.75 µF < 2 KV 0.04 µF < 5 KV
DC Mode 0.5 µF < 3 KV
AC Output Waveform Sine Wave, Crest Factor = 1.3 - 1.5
Output Regulation ± (1% of output + 5 V) from no load to full load and over
input voltage range.
Dwell Timer Range: AC 0.4 - 999.9 sec (0 = Constant)
DC 0.3 - 999.9 sec (0 = Constant)
Ramp Timer Range: Ramp-Up: AC 0.1 - 999.9 sec, DC 0.4 - 999.9 sec
Ramp-Down: AC 0.0 - 999.9 sec, DC 0.0,1.0 - 999.9 sec
Ground Continuity Current: DC 0.1 A ± 0.01 A, fixed
Max. Ground Resistance: 1
Ω ± 0.1 Ω, fixed
Ground Fault Interrupt GFI Trip Current: 450 µA max (AC or DC)
HV Shut Down Speed: < 1ms
Continuity Test Mode
Output Current DC 0.1A ± 0.01A, fixed
Resistance Display/ Range: 0.00 - 10.00 Ω
HI and LO-Limit
Dwell Timer Range: 0.0, 0.3 - 999.9 sec (0 = Constant)
Milliohm Offset Range: 0.00 - 2.00 Ω
Ground Bond Test Mode
Output Voltage Range: 3.00 - 8.00 VAC
(Open Circuit Limit) 50/60 Hz, user selectable
Output Current Range: 1.00 - 40.00 A, Resolution: 0.01 A
Output Regulation Accuracy: ± (1% of output + 0.02 A)
Within maximum load limits, and over input voltage range
Maximum Loading 1.00 - 10.00 A, 0 - 600 m Ω
10.01 - 30.00A, 0 - 200 m Ω
30.01 - 40.00A, 0 - 150 m Ω
Ohmmeter Display/ 0 - 150 m Ω for 30.01 - 40.00 A
HI and LO Limit 0 - 200 m Ω for 10.01 - 30.00 A
0 - 600 m Ω for 6.00 - 10.00 A
Accuracy: ± (2% of reading + 2 m Ω)
0 - 600 m Ω for 1.00 - 5.99 A
Accuracy: ± (3% of reading + 3 m Ω)
Milliohm Offset Range: 0 - 200 m Ω
Insulation Resistance Test Mode
Voltage Setting Range: 50 - 1000 VDC
Charging Current Maximum >20 mA peak
Resistance Display/ Range: 0.05 M Ω - 50000 MΩ (4 Digit, Auto Ranging)
HI and LO Limit Accuracy:
50 - 499 V
0.05 M Ω - 999.9 MΩ, ± (7% of reading +2 counts)
500 - 1000 V
0.05 M Ω - 999.9 MΩ, ± (2% of reading +2 counts)
1000 M Ω - 9999 MΩ, ± (5% of reading +2 counts)
10000 M Ω - 50000 MΩ, ± (15% of reading +2 counts)
Insulation Resistance Test Mode (Continued)
Charge LO Range: 0.000 - 3.500 µA or Auto Set
Ramp Timer Range: Ramp-Up: 0.1 - 999.9 sec
Ramp-Down: 0.0, 1.0 - 999.9 sec
Delay Timer Range: 1.0 - 999.9 sec (0 = Constant)
Ground Fault Interrupt GFI Trip Current: 450 µA max (AC or DC)
HV Shut Down Speed: < 1 ms
General Specifications
Mechanical Bench or rack mount with tilt up front feet
Dimensions 3U (WxHxD) 17 x 5.8 x 20.3 in.
(432 x 147 x 515 mm)
Weight 51.68 lbs (23.44 kgs) varies with option
Interface RS-232 standard or select GPIB or Printer
Port with time and date stamp.
Safety Built-in SmartGFI ® circuit
Memory 50 memories, 30 step/memor y
OMNIA 8105 and 8106 Functional Run Test Mode
Delay Time Setting Range: 0.2 - 999.9 seconds
Dwell Time Setting Range: 0.1 - 999.9 seconds (0 = constant)
Trip Point Settings and Metering
Voltage Volt-Hi/Volt-LO Range: 0.0 - 277.0 VAC (one hot and one neutral)
Current Amp-HI/Amp-LO Range: 0.1 - 15.00 AAC
Watts Watt-HI/Watt-LO Range: 0 - 4200 W
Power Factor
PF-HI/PF-LO
Range: 0.000 - 1.000
Leakage Current
Leak-HI/Leak-LO
Range: 0.00 - 10.00 mA (0 = OFF)
Timer Display Range: 0.0 - 999.9 seconds
OMNIA 8106 Line Leakage Test Mode (DUT Power)
Voltage 0 - 277 VAC
Current 15 AAC max. continuous
Short Circuit Protection 23 AAC, Response Time < 3 sec
Leakage Current
Current Display Range 1: 0.0 µA - 999.9 µA
RMS or PEAK Range 2: 1000 µA - 6000 µA
Accuracy RMS DC to 100 kHz, ± (1.5% of reading+ 3 counts)
>100 k to 1 MHz
± 5% of reading, (10.0 µA - 6000 µA)
Accuracy PEAK DC to 1 MHz, ± (10% of reading + 2 µA)
Measuring Device A UL544 Non Patient
B UL544 Patient
C IEC601-1, UL2601, EN60601-1
D UL1563
E IEC1010, UL3101, IEC950, UL1950,
IEC60990 FIG. 4 - U2
H IEC60990 FIG. 5 - U3
I IEC60990 FIG. 3 - U1
MD A-D and H-I components Accuracy: Resistance ± 1%, Capacitance ± 5%
MD E components Accuracy: Resistance ± 0.1%, Capacitance ± 1%
MD Voltage Limit Maximum 30 V peak or 30 VDC
HI and LO-Limit Range: 0 - 6000 µA (0 = OFF)
Delay Timer Range: 0, 1.0 - 999.9 sec (0 = Constant)
