Specifications, Ordering information – Atec Chroma-12061 User Manual
Page 4

specifications
DC Voltage
Range
Resolution
Input
Resistance
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
100.000mV
0.1μV
>10GΩ
0.0050 + 0.0035
1.000000V
1.0 μV
0.0040 + 0.0007
10.00000V
10 μV
0.0035 + 0.0005
100.0000V
100 μV
10MΩ
0.0045 + 0.0006
1000.000V
1mV
0.0045 + 0.0010
DC Current
Range
Resolution
Shunt
Resistance
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
10.00000mA
10nA
5.1Ω
0.050 + 0.020
100.0000mA
100nA
0.050 + 0.005
1.000000A
1μA
0.1Ω
0.100 + 0.010
3.00000A
10μA
0.120 + 0.020
AC RMS Voltage
Range
Resolution
Frequency
(Hz)
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
100.0000mV
0.1μV
3 ~ 5
1.00 + 0.04
5 ~ 10
0.35 + 0.04
10 ~ 20K
0.06 + 0.04
20K ~ 50K
0.12 + 0.05
50K ~ 100K
0.60 + 0.08
100K ~ 300K
4.00 + 0.50
1.000000V ~
750.000V
1.0μV ~ 1mV
3 ~ 5
1.00 + 0.03
5 ~ 10
0.35 + 0.03
10 ~ 20K
0.06 + 0.03
20K ~ 50K
0.12 + 0.05
50K ~ 100K
0.60 + 0.08
100K ~ 300K
4.00 + 0.50
AC RMS Current
Range
Resolution
Frequency
(Hz)
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
1.000000A
1μA
3 ~ 5
1.00 + 0.04
5 ~ 10
0.30 + 0.04
10 ~ 5K
0.10 + 0.04
3.000000A
1.0μA
3 ~ 5
1.10 + 0.06
5 ~ 10
0.35 + 0.06
10 ~ 5K
0.15 + 0.06
Resistance (4W Measurement)
Range
Resolution
Test Current
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
100Ω
100μΩ
1mA
0.010 + 0.004
1.000000kΩ
1mΩ
1mA
0.010 + 0.001
10.00000kΩ
10mΩ
100μA
0.010 + 0.001
100.0000kΩ
100mΩ
10μA
0.010 + 0.001
1.000000MΩ
1Ω
5μA
0.010 + 0.001
10.00000MΩ
10Ω
500nA
0.040 + 0.001
Diode Test
Range
Resolution
Test Current
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
1.00000V
10μV
1mA
0.010 + 0.020
Continuity Test
Range
Resolution
Shunt
Resistance
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
1000.00Ω
100mΩ
1mA
0.010 + 0.030
Frequency and Period
Range
Frequency (Hz)
1 year accuracy
±
(reading%+range%)
(23℃±5℃)
100mV ~ 750V
3 ~ 5
0.1
5 ~ 10
0.05
10 ~ 40
0.03
40 ~ 300K
0.01
Measurement Characteristics
Math Functions
NULL, min / max / average, dBm, dB, MX+B,
RATIO, %, limit test (with TTL output)
Measurement
Noise Rejection
60Hz(50Hz)
DC CMRR:140 dB
AC CMRR:70 dB
Integration Time
& Normal Mode
Rejection NMRR
10 plc/167 ms (200 ms):60 dB
1 plc/16.7 ms (20 ms):60 dB
DC Voltage
Input bias current:25℃ < 30pA
Input protection:1000V
DC Current
Input protection: External 3 A 250V fuse
AC Voltage
Input impedance: 1 MΩ parallel with 100 pF
Input protection: 750Vrms all ranges
AC Current
Input protection: External 3 A 250V fuse
Resistance
Maximum lead resistance (4-wire):
10% of range per lead for 100Ω and 1kΩ ranges.
1kΩ per lead on all other ranges.
Input protection: 1000 V all ranges
Continuity/Diode
With audible tone
Continuity threshold: Selectable from1Ω to 1000Ω
Temperature
Thermocouple:
E, J, K, N, R, S and T type sensors supported.
RTD: 2-wire, 3-wire and 4-wire measurement
Temperature Conversion:
ITS-90, IEC751, Callendar-Van Dusen
External Control
Samples/Trigger
1 ~ 50,000
Trigger Delay
0 ~ 3600 sec.
Memory
2000 readings
Standard
Complier
SCPI (IEEE-488.2)、Agilent 34401
Interface
USB (standard),GPIB (option)
General
Power
Consumption
25VA max.
Power
Requirements
100 V/120 V/220 V/240 V,45 Hz ~ 440 Hz
Operation
Environment
8.5(H) x 21(W) x 35(D) cm
Weight
Approx. 4.36 kgs
All specifications are subject to change without notice.
Distributed by:
Worldwide Distribution and Service Network
12061-E-200808-PDF
CHINA
CHROMA ELECTRONICS
(SHENZHEN) CO., LTD.
8F, No.4, Nanyou Tian An
Industrial Estate, Shenzhen,
China PC: 518054
Tel: +86-755-2664-4598
Fax: +86-755-2641-9620
EUROPE
CHROMA ATE EUROPE B.V.
Morsestraat 32
NL-6716 AH Ede
The Netherlands
Tel: +31-318-648282
Fax: +31-318-648288
U.S.A.
CHROMA ATE INC. (U.S.A.)
7 Chrysler Irvine, CA 92618
Tel: +1-949-421-0355
Fax: +1-949-421-0353
Toll Free: +1-800-478-2026
CHROMA ATE INC.
致茂電子股份有限公司
HEADQUARTERS
66, Hwa-Ya 1st Rd., Hwa-Ya
Technology Park, Kuei-Shan Hsiang,
Taoyuan Hsien 333, Taiwan
Tel: +886-3-327-9999
Fax: +886-3-327-8898
http://www.chromaate.com
E-mail: [email protected]
Developed and Manufactured by :
12061
: 6½ Digital Multimeter
A120000
: Multi-point Scanner Card
A120001
: Thermal-measurement Adapter
ordering information
