Design is subject to change without any notice for the improvement purpose. 2011.02.
SPECIFICATIONS
Description Subject
Arc Fusion Splicer
AC Adapter
Sleeve Loader
Spare Electrodes
Battery Pack
Alcohol dispenser
Carrying Case
User Manual
S3
S311
S312
EI-21
S313
1
1
2
1
1
1
1
1
Model Q’ty Description
STANDARD PACKAGE
Battery Pack
Fiber Cleaver
Heating Stripper
Fiber Solution
Protection Sleeves
Cleaver Blade
S313
CI-01, CI-02, CI-03, CI-03B
Auto Stripper(ATS)
Multipack(MP-S)
S-160(60mm), S-140(40mm)
BI-05
Model Description
OPTION
Alignment
Applicable fibers
Fiber Diameter
Fiber cleave length
Typical splice loss
Return loss
SPLICE Time
Program
Storage of splice result
Operating altitude
Operating condition
Storage condition
Protection
SIZE, Weight
Terminal
Power
Additional power
No of splice/Heating with Battery
Electrode
Mechanical proof test
Display
Fiber view and magnification
IPAS Core to Core Alignment (Image Pattern Analysis Alignment System)
SMF(ITU-T G.652), MMF(ITU-T G.651), DSF(ITU-T G.653), NZDSF(ITU-T G.655),
EDFA, EI980, Splicing available with different type fiber(SM/MM), ITU-T G.657
cladding : 80 ~ 150 , coating : 100 ~ 1000 (single)
250 (Coat) : 8 ~ 16mm, 900 : 16mm
SMF : 0.02dB, MMF : 0.01dB, DSF : 0.04dB, NZDSF : 0.04dB
Less then -60dB
SPLICE : Typical 9sec, Tube Heat : Typical 26sec with S-160(60mm) Tube
SPLICE Mode : 100, Heat Mode : 50
the last 2,000 results (Image 100 results)
0 ~ 5000m above sea level
-10 to 50 , humidity : 95%, non-Condensing
-40 to 80 , 0 to 95% RH
Wind 15 , shock proof, water proof, dust proof
138W 160L 135H (include Monitor & Rubber), 2.3Kg (include Battery)
USB, RCA, External Power
DC 14.8V Battery (5600mAh), 100 ~ 240V AC Adapter
DC 12V automobile power outlet available
250cycle, lithium polymer batteries
more than 2,000 times splicing without exchange
2N / 4.4N (OPTION)
Two CMOS cameras and 4.3 color LCD monitor, with touch panel
X/Y 300X, 170X
