10
Specifications
Applicable fiber 10/125 µm SM fiber (ITU-T G.652)
Optical connector User replaceable (FC, SC, ST, DIN, HMS-10/A), Factory option (E2000, FC-APC, SC-APC, HRL-10)
Range: 1450 to 1650 nm
Accuracy: ±20 pm (1550 ±20 nm, room temperature), ±50 pm (1520 to 1600 nm),
±0.3 nm (all range) *After wavelength calibration
Wavelength
Stability: ±5 pm (smoothing: 11 pt, 1 minute, at half-width of center wavelength)
Linearity: ±20 pm (1550 ±20 nm)
Read resolution: 5 pm (display resolution: 1 pm)
Setting resolution: 0.1, 0.2, 0.5, 1.0 nm (filter: 3 dB bandwidth)
Resolution accuracy:
≤
±10% (1550 ±20 nm, 0˚ to 30˚C),
≤
30% (1550 ±100 nm, 0˚ to 30˚C)
Measurement level ranges:
–87 to +10 dBm (1450 to 1600 nm, 0˚ to 30˚C), –72 to +10 dBm (1600 to 1650 nm, 0˚ to 30˚C),
–82 to +10 dBm (1450 to 1600 nm, 30˚ to 50˚C), –67 to +10 dBm (1600 to 1650 nm, 30˚ to 50˚C),
Level
–68 to +23 dBm (1450 to 1600 nm, 0˚ to 30˚C, internal optical attenuator: on)
Accuracy: ±0.4 dB (1550 nm, –23 dBm)
Stability: ±0.02 dB (1550 nm, –23 dBm, 1 minute, constant temperature, no polarization fluctuation)
Linearity: ±0.05 dB (1550 nm, –50 to 0 dBm)
Flatness: ±0.1 dB (1550 ±20 nm), ±0.3 dB (1520 to 1600 nm)
Polarization dependency ±0.15 dB
Dynamic range 58 dB (at point 1 nm from peak), 53 dB (at point 0.5 nm from peak)
Optical return loss 35 dB (1550 nm)
SLD output >–40 dBm/nm (at 1550 nm)
Display 6.4-inch color TFT-LCD
Memory trace Three measurement memories and three trace displays
Printer Internal (thermal type)
Interface GPIB, RS-232C, monitor output (VGA compatible)
Data save/output 3.5-inch floppy disk drive
Operating temperature: 0˚ to +50˚C (however, 5˚ to 50˚C for FDD)
Ambient conditions Storage temperature: –20˚ to +60˚C
Relative humidity:
≤
90% (no condensation, 20% to 80% for FDD)
Power 85 to 132 Vac/172 to 250 Vac, 47.5 to 63 Hz, 150 VA (max.)
Dimensions and mass 320 (W)
×
177 (H)
×
350 (D) mm (excluding projections),
≤
16.5 kg
Note: Warm-up to the MS9720A for about 5 minutes to ensure stable operation. The above specifications are obtained at 2-hours after power-on.
