The CMA5200 OTDR’s are Single Bay modules that include one OTDR/Source Universal Adapter (UC-130-XX) at no charge.
For units with a Power Meter option, a Meter Connector Adapter (LP-XX) is also included at no charge.
Additional OTDR modules are available in various combinations of wave lengths and dynamic ranges.
Please contact Anritsu for a comprehensive list.
Ordering Information
Please specify the model/order number, name and quantity when ordering.
The names listed in the chart below are Order Names. The actual name of the item may differ from the Order Name.
•
Module Number:
52 - - OTDR -
A B C
A = Select an OTDR Module
25 = Singlemode, 37/36 dB dynamic range, dual-wavelength 1310 nm/1550 nm
45 = Singlemode, 43/45 dB dynamic range, dual-wavelength 1310 nm/1550 nm
46 = Singlemode, 43/45/43 dB dynamic range, tri-wavelength 1310 nm/1550 nm/1625 nm
54 = Singlemode, 50 dB dynamic range, single-wavelength 1550 nm
B = Select Meter, Light Source and VFL Options
000 = No Meter, Light Source or VFL
001 = VFL Only
210 = +20 dBm Meter and Light Source
211 = +20 dBm Meter, Light Source and VFL
C = Select Connector
UFC = FC/UPC AFC = FC/APC
USC = SC/UPC ASC = SC/APC
UST = ST/UPC AST = ST/APC
