OptiVisor ™
400
Optical Time
Domain Reflectometer (OTDR)
A LANscape ® Solutions Product
Specifications
Multimode Module 1
Dynamic Range 2 Event Dead Attenuation
Model Wavelength (nm) at 100 ns/1µs (dB) Zone 3 (m) Dead Zone 3 (m)
400-MD25-XX 4 850 ± 20/1300 ± 20 23/27 1.5/1.5 5/5
Single-mode Module 1
Dynamic Range 2 Dynamic Range 2 Event Dead Attenuation
Model Wavelength (nm) at 10 µs (dB) at 20 µs (dB) Zone 5 (m) Dead Zone 5 (m)
400-SD34-YY 1310 ± 20/1550 ± 20 35/34 36/35 1/1 5/6 (4/4) 6
400-SD37-YY 1310 ± 20/1550 ± 20 38/37 39/38 1/1 5/6 (4/4) 6
400-SD135-YY 1550 ± 20/1625 ± 10 37/35 38/36 1/1 6/6 (4/5) 6
400-ST37-YY 1310 ± 20/1550 ± 20/1625 ± 10 38/37/35 39/38/36 1/1/1 5/6/6 (4/4/5) 6
400-ST137-YY 1310 ± 20/1490 ± 10/1550 ± 20 38/34/37 39/35/38 1/1/1 5/6/6 (4/4/4) 6
400-SD40-YY 1310 ± 20/1550 ± 20 40/40 10 41.5/40.5 10 3/3 10/15
400-SD140-YY 1550 ± 20/1625 ± 10 40 10 /38 40.5 10 /39 3/3 15/16
400-SD45-YY 7 1310 ± 20/1550 ± 20 43.5/43.5 11 45/45 11 3/3 10/15
400-SD142-YY 7 1550 ± 20/1625 ± 10 43.5 11 /41.5 45 11 /43 3/3 15/16
400-ST41-YY 1310 ± 20/1550 ± 20/1625 ± 10 41/40/38 42.5/41.5/39.5 3/3/3 8/10/10
400-SD34/ 400-SD40/SD140/SD45/
General Specifications 400-MD25 SD37/SD135/ST37/ST137 SD142/ST41
Distance Range (km) 0.625, 1.25, 2.5, 5, 10, 1.25, 2.5, 5, 10, 20, 40, 1.25, 2.5, 5, 10, 20, 40, 80,
20, 40 80, 160, 260 160, 260
Pulse Width (ns) 10, 30, 100 (850 nm) 5, 10, 30, 100, 275, 1000, 10, 30, 100, 275, 1000,
10, 30, 100, 275, 1000 (1300 nm) 2500, 10,000, 20,000 2500, 10,000, 20,000
Linearity (dB/dB) ± 0.05 ± 0.03 ± 0.05
Loss Threshold (dB) 0.01 0.01 0.01
Loss Resolution (dB) 0.001 0.001 0.001
Sampling Resolution (m) 0.08 to 5 0.04 to 5 0.08 to 5
Sampling Points Up to 16,000 Up to 128,000 Up to 52,000
Distance Uncertainty 8 (m) ± (1 + 0.0025 % x distance) ± (0.75 + 0.0025 % x distance) ± (1 + 0.0025 % x distance)
Measurement Time User-defined User-defined User-defined
(60 min. maximum) (60 min. maximum) (60 min. maximum)
Real-time Refresh (s) ≤ 1 Guaranteed: ≤ 0.4 ≤ 1
Typical: ≤ 0.3
Stable Source Output Power 9 (dBm) -7 -8 (400-SD34); -4.5 (all others) -5
Visual Fault Locator (optional) Laser, 650 nm ± 10 nm Laser, 650 nm ± 10 nm Laser, 650 nm ± 10 nm
CW, P
out
maximum: ≤ 800 µW CW, P
out
maximum: ≤ 5 µW CW, P
out
maximum: ≤ 800 µW
Notes:
1 All specifications valid at 23ºC ± 2ºC (73.4ºF ± 3.6 oF) with an FC/PC connector, unless otherwise specified.
2 Typical dynamic range with a three-minute averaging at SNR = 1 (for 400-SD34/SD37/SD135/ST37/ST137, typical dynamic range
with 45-second averaging is only 1 dB lower than values given for three-minute averaging).
3 Typical dead zone of multimode modules for reflectance below -35 dB using a 10 ns pulse.
4 ORL measurement not available for this module.
5 Typical dead zone of single-mode modules for reflectance below -45 dB, using a 10 ns pulse (5 ns pulse for 400-SD34/SD37/SD135/ST37/ST137).
6 Typical dead zone of 400-SD34/SD37/SD135/ST37/ST137 single-mode modules for reflectance below -55 dB, using a 5 ns pulse.
7 Typical dynamic range on NZDS fiber with a three-minute average at SNR = 1.
8 Does not include uncertainty due to fiber index and sampling resolution.
9 Typical output power value at 1550 nm.
10 Typical dynamic range at 1550 nm for the 400-SD40 configuration is 2 dB lower at 10 µs and 1 dB lower at 20 µs.
11 Typical dynamic range at 1550 nm for the 400-SD45 configuration is 2 dB lower.
