Quick Fact Sheet
Site Master ™ S810D / S820D
Broadband Cable & Antenna Analyzer
11410-00638, Rev. A Printed in United States 2012-01
©2012 Anritsu Company. All Rights Reserved.
® Anritsu All trademarks are registered trademarks of their respective companies.
Data subject to change without notice. For the most recent specifications visit: www.anritsu.com
www.anritsu.com or 1-800-267-4878
Optional Accessories
Portable Antennas Adapters
Pricing | Ordering | Training | Support
Key Specifications
Analyzer Performance
Frequency 2 MHz to 10.5 GHz (S810D) 2 MHz to 20 GHz (S820D)
Frequency Accuracy (Fixed CW On) ≤ 3 ppm at +25 ºC
Sweep Speed 2.5 msec / data point
Output Power (from RF Out Port) <0 dBm (at any particular frequency)
General
Internal Trace Up to 200 traces, 21 setups
Connectivity 9 pin D-sub
Display TFT color display with adjustable backlight
Temperature Operating Temperature –10 ºC to 55 ºC, humidity 85% or less
Power Supply External: DC input: +12 to +15 Volt DC, 5A Internal: NiMH battery:
10.8 volts, 1800 mAh
Dimensions 254 mm x 178 mm x 61 mm (10.0 in x 7.0 in x 2.4 in)
Weight: <2.28 kg (<5 lbs) including battery
Standard Accessories
Part Number Description
10680-00001 Site Master S810D/S820D User’s Guide
2300-347 Anritsu Handheld Software Tools CD ROM
48258 Soft Carrying Case
633-27 Rechargeable NiMH Battery
34RKNF50 Precision Adapter, Ruggedized K(m) to N(f)
40-168 AC/DC Adapter
806-141 Automotive Cigarette Lighter/12 Volt Adapter
800-441 Serial Interface (Null Modem) Cable
551-1691-R USB to RS-232 Adapter Cable
Options
Option Number Description
S8x0D/2 2 MHz Low Frequency Extension
S8x0D/5 Power Monitor
(detector not included)
S8x0D/11NF Replaces standard K(f) Test Port Connector with N(f)
S8x0D/22SF SMA 2-Port Cable Loss includes the following bundled items:
CWM220B-SF, SMA(f) CW Source Module
560-7S50B, WSMA(m) RF Detector
S8x0D/5, Power Monitor
66379, DIN to D-sub adapter cable for Power Monitor
S8x0D/2, 2 MHz Low Frequency Extension
S8x0D/22NF N(f) 2-Port Cable Loss includes the following bundled items:
CWM220B-NF, N(f) CW Source Module
560-7N50B, N(m) RF Detector
S8x0D/5, Power Monitor
66379, DIN to D-sub adapter cable for Power Monitor
S8x0D/2, 2 MHz Low Frequency Extension
S8x0D/31 GPS Receiver
(includes 2000-1410 GPS antenna)
