2
2. It will run through a self-test and when
completed it displays the Main Menu as
shown below:
New: Clear Memory
Clear the last tested results stored in its memory.
Continue Test…
Continue the last test on the same car from where
you had stopped.
Last Test Result
Review the test results of the last tested car
After you have made your choice, selecting “New:
Clear Memory” or “Continue Test…” press
will proceed to the display below:
BATTERY TEST
3. If it has detected any surface charge on the
battery, it will start to remove and a message
is shown below.
4. If the surface charge is too great for the
analyser to handle, it will prompt you with the
instructions as shown below.
5. Wait until the surface charge removal had
completed, the tester will advise as follows
and then press key.
6. If there is no surface charge present, then it
will straight away enter into “Select Battery”
menu screen as shown below:
7. Pressing again will proceed to Battery
Test as shown below.
Grounding Test
Starter Test
Alternator Test
IEC SAE
EN JIS# CA
DIN Unknown
Select Rating
CCA
Battery Test
New: Clear Memory
Last Test Result
Select Test
Continue Test...
AGM [Flat/Spiral]
Select Type
SLI [Wet]
Removing Surface
Charge...
Please Wait!
Turn ign.key ON.
Headlights ON to
remove Surface
Surface Charge
now removed. Key
& headlights OFF
