8 164201241-001 Rev. C0
2.1 Electrical & Mechanical Specifications, continued
Cabinet type Height Width Depth Weight
Pole Mount 386mm (15.2") 197mm (7.3") 213mm (8.4") 15kg (33lb)
Ground Mount 561mm (22.2") 197mm (7.3") 213mm (8.4") 16kg (35lb)
MECHANICAL SPECIFICATIONS
Indoor Enclosure 350mm (13.8") 179mm (7.0") 170mm (6.7") 16kg (35lb)
230 Vac, 50Hz +15% / -20% 230 Vac, 50Hz +15% / -20%
900VA maximum @ 60V
(15A resistive)
540VA maximum @ 60V
(9A resistive)
3.0A
9A (maximum)
PSF-W00-D09
230VAC, 50Hz (CE) MODELS
Indoor/Wall Mount
Input Voltage
Input Current (@ 60V, 15A
Nominal)
Output Voltage
Output Current
Full Load Efficiency (typical)
Output Power
Operating Environment
ELECTRICAL SPECIFICATIONS
PSF-W00-D15
90%
Temperature: -40°C to 55°C (-40°F to 131°F)
Humidity: 0 to 95% (noncondensing)
60Vrms Quasi-square wave ±3%
15A (maximum)
4.8A
88%
