1.3 Specifications
MODEL APP60S APP60S E APP6014S-J5
Input
Voltage (VAC) 120 ±15% 220/240 ±15% 100/115 ±15%
Frequency (Hz) 60 50 50
Current Max. (A) 9 4.8 12
Output
Voltage (VAC) 60/30 ±5% 60/30 (60/48) ±5% 30/60 ±5%
Current (A) 14 14 14
Power (VA) 840 840 420/840
Output Current Limit 150% of maximum output rating
Efficiency 90% typical @ rated load
Operating Temperature Range -40 0 to +122 0 F (-40 0 to +50 0 C)
Dimensions 7" W x 10" H x 13" D (170mm x 250mm x 330mm)
Weight 34 lbs. (15 kg)
FinishASA 61 Gray Epoxy Powder Paint
Specifications @ 77 0 F (25 0 C)
