3. INSTALLATION AND OPERATION
7
3.1 APP60S Installation and Power Module Removal
Plug the AC Line cord into
enclosure's convenience outlet
Plug the "Jones" connector into
Service Power Inserter's mating connector
Select required
output voltage
Switch the unit ON
Fig. 5
APP60S Installation and Wiring
