1.0 Introduction
The Alphagen DCX2000 portable DC generator supplies DC voltage to a power supply battery bus when
commercial AC power is not available. The generator is designed to be temporarily connected to the DC bus
of a standard Alpha 36V uninterruptable power supply (UPS). Upon loss of commercial AC power, the existing
batteries immediately supply the power supply inverters. After some interval of battery discharge, an operator
deploys the portable generator at the site to supply power to the DC bus.
1.1 DCX2000 Generator Components
Fig. 1-1, DCX2000 Generator Components
Spark Plug Access Cover
Gas Cap
Control Panel
Starter Grip
Choke Lever
Exhaust Grill
Maintenance
Panel
Fuel
Valve
Fuel Primer
Spark Arrestor
OUTPUT BREAKER
LCD Display
V: 40.3V I: 00.0A
P:0000W
Oil: OK ALM:
Time: 004H 27M
Ground Stud
DC OUTPUT
OUTPUT
ALARM
OIL
ENGINE
ON
OFF
ON
OFF
