4. Signal Definitions

19

704-683-B0-004, Rev. D

4.1 USM2.5 Signal Definition,

continued

Name:

Output Fail Alarm

Pin:

J4-10

Signal Type:

USM2.5 Discrete Output

Referenced to:

Common (J4-1, J4-12)

Description:

This USM2.5 signal indicates the state of the AC output. A non-
latching signal, the Output Alarm will match the state of the
power supply output in real-time.

Active Means:

The XM2’s AC output has failed.

Active State:

LOW

Inactive Means:

The XM2’s AC output is OK.

Inactive State:

HIGH

NOTE:

Removing the output fuse will result in a loss of power to the cable system (load).
Do not attempt this test without first transferring the load to a Service Power Supply

How to Test:

Remove the XM2’s AC output fuse; verify J4-10 is LOW. Return
the XM2’s fuse; verify J4-10 is HIGH.

Name:

Test/Reset

Pin:

J4-11

Signal Type:

USM2.5 Discrete Input

Referenced to:

Common (J4-1, J4-12)

Description:

This USM2.5 input controls remote test of the XM2’s inverter and
allows reset of a latched USM2.5 Equipment Fail Alarm. This
control signal originates from the transponder.

Active Means:

An active Test / Reset pin indicates that the XM2 has been
commanded to initiate and hold a remote inverter test.

Active State:

LOW, a transition from HIGH to LOW will indicate to the USM2.5
that the Test/Reset pin has been activated. The pin will be
considered active by the USM2.5 for the duration that the pin is
held LOW.

Inactive Means:

The XM2 is not commanded to perform or hold a remote inverter
test. Any previously held test will be ended when the input is
transitioned from active to inactive.

Inactive State:

HIGH

How to test:

To perform a test at the XM2, disconnect the transponder from
the USM2.5. With line and battery applied to the XM2, carefully
short and hold the Test/Reset J4-11 to ground (J4-1), the XM2 will
immediately start inverter test mode. Wait at least 1 minute then
release J4-11 from ground and the inverter test mode will end,
and any latched Equipment Fail Alarm should clear.

Resetting a latched Equipment Fail Alarm:

If a USM2.5 Equipment Fail Alarm is latched when the Test/
Reset pin is made active and a successful inverter test is
completed, the Equipment Fail Alarm will be cleared (i.e. J4-6
change to inactive).
