19 745-420-C0-002 Rev. B
5.0 Specifications
DOCSIS ® Network Power Monitoring
General Specifications
General
Power Supplies Supported: XM2, XM2VP
DOCSIS Compatibility: DOCSIS 1.1
Monitoring Protocol: SNMPv1
Devices Monitored: Power Supply, Batteries and Generator
compatible with ANSI/SCTE 25-3 2002,
(formerly HMS 022)
Hardware
RF Cable Interface: F-connector, female, 75ohm
Local Interface: RJ-12, RS-232, 19.2kb,N,8,1
Requires serial port adapter and with
terminal emulation software (Hyper-
Terminal recommended)
LED Indicators: Transponder Ready; HMS Communi-
cations; RF Transmit; RF Receive
Environmental: -40ºC to +65ºC
10 to 90% non-condensing humidity
Emissions: EN50022 Class A and FCC Part 15 Class
A (Installed in power supply enclosure system)
Warranty: 2 years
RF Transmit / Receive
Tx Frequency Range: 5 to 42 MHz
Output Power: +8 to +58 dBmV
Channel Bandwidth: 6 MHz
Receive Center Freq Range: 91 to 857 MHz (Standard, HRC, IRC
channels)
Input Level: -15 to +15 dBmV
Monitored Parameters
Number of Power Supplies: Up to six, each reporting individual data
Power Supply Data: Major Alarm (includes: test fail, battery fail,
line isolation, output over load/fault, over
temp, N+1 active, fuse fail)
Minor Alarm (includes: temp probe error, AC
line loss, N+1 error)
Input AC Line Voltage
Output Voltage
Output Current 1
Output Current 2,3,4 (if installed)
Output Power
Power Supply Status (line, standby, test in
progress, test alarm)
Enclosure Door (open/closed)
Power Supply Control: Remote test start/stop
Number of Battery String: One or Two Strings of 36V or 48V
Additional battery string monitoring available.
Call Alpha for more information.
Battery Data: Individual Battery Voltages
Battery Compartment Temperature
Generator Data: Status (off, running, alarm)
(Alarm includes: low oil pressure, engine over-
temp, engine over-speed, crank limit, over-
voltage, low fuel, water intrusion, pad shear,
gas hazard, test fail)
Gas hazard
Water Intrusion
Pad Shear
Enclosure Door (open/closed)
Ignition Battery Voltage
Enclosure Temperature
Low Fuel
Generator Control: Remote test (start/stop)
Management
NMS/EMS: Cheetah™ DOCSIS ® Power Supply
Management Software
Standard SNMP Management Tools
HMS MIBs: Power Supply (ANSI/SCTE 38-4)
Generator (ANSI/SCTE 38-6)
Transponder (ANSI/SCTE 38-3)
Alarm/Trap (ANSI/SCTE 38-1 and 38-2)
Ordering Information
EDSM-IDH2 DOCSIS Monitoring
DCS-XM2V-2 (XM2VP) Includes: transponder with VoIP test
function, EDSM and bracket. Order
AlphaGuard Battery Management or wire
sense kit separately.
IDH2 DOCSIS Embedded XM2 Transponder
with VoIP Test Function( For installation
with existing EDSM. Order AlphaGuard
Battery Management or wire sense kit
separately.
875-349-10 Local port adaptor
875-155-20 10-pin Connector
Battery Sense Wire Kits
874-842-21 1x36V, 6 ft
874-842-20 2x36V, 6 ft
874-842-27 1x36V, 9 ft
874-842-28 2x36V, 9 ft
874-841-21 1x48V, 6 ft
874-841-20 2x48V, 6 ft
874-841-25 1x48V, 9 ft
874-841-24 2x48V, 9 ft
Extended wire lengths available. Contact Alpha for ordering information.
SI-XM2-KIT (XM2) Additional XM2 Interface Kit
SI-XM2V-KIT (XM2VP) Includes SI adaptor and integration kit
for connecting an additional power
supply for monitoring. One kit required
for each additional power supply (up to
six total).
