16 745-420-C0-002 Rev. B
3.0 Network/Element Management Software
3.1 Provisioning the SNMP Manager
The following MIB (Management Information Base) files are required for the SNMP Manager to
collect data from the transponders. These files can be found on the Society of Cable
Telecommunications (SCTE) web site www.scte.org. These are dependencies between MIB files
so they should be compiled in the following order listed below:
ANSI/SCTE 36 2002 (formerly HMS 028), SCTE-ROOT Management Information Base (MIB)
Definitions
ANSI/SCTE 37 2003 (formerly HMS 072), Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-ROOTS Management Information Base (MIB) Definition
ANSI/SCTE 38-1 2002 (formerly HMS 026), Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-PROPERTY-MIB Management Information Base (MIB) Definition
ANSI/SCTE 38-2 2002 (formerly HMS 023), Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-ALARMS-MIB Management Information Base (MIB) Definition
ANSI/SCTE 38-3 2002 (formerly HMS 024), Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-COMMON-MIB Management Information Base (MIB) Definition
ANSI/SCTE 38-4 2002 (formerly HMS 027), Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-PS-MIB Management Information Base (MIB) Definition
ANSI/SCTE 38-6 2003 (formerly HMS 033) Hybrid Fiber/Coax Outside Plant Status Monitoring -
SCTE-HMS-GEN-MIB Management Information Base (MIB) Definition
ANSI/SCTE 38-7 2002 (formerly HMS 050), Hybrid Fiber/Coax Outside Plant Status Monitoring
SCTE-HMS-Transponder-Interface-Bus(TIB)-MIB Management Information Base (MIB) Definition
3.2 Transponder Acquisition by the SNMP Manager
The transponder must first complete its initialization/registration and retrieve the .ini file from
the TFTP server. The transponder will then send a warm-start trap to the SNMP Manager
(specified as the Server IP in the .ini file). This trap provides the SNMP Manager with the
MAC and IP addresses of the transponder and should, depending on the configuration of the
manager software, initiate monitoring of the power supply system.
