Alpha Technologies Cordex Controller Panel Mount_Rack Mount 125_220Vdc - Manual (Page 26)

131 5.16
425.5 16.75
171 6.73
155 6.10
175.3 6.90 175.3 6.90 37.5 1.48
8 .31
FRONT VIEW
TOP VIEW
99.1 3.90
SIDE VIEW
FRONT ISOMETRIC VIEW
SIZE DWG NO. TYPE
B
SHEET
TITLE
ISSUE
D A T E
OF
TOLERANCES
SCALE
APPROVED
CHECKED
DRAWN
DESIGN MATERIAL
FINISH
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
LTR
FINISHED HOLE LEGEND
QTY DESCRIPTION
REVISIONS
LTR DESCRIPTION APPD DATE
REV
X.X 0.04"
X.XX 0.02"
X.XXX 0.01"
[X] 1mm
[X.X] 0.5mm
[X.XX] 0.25mm
018-570-06
OUTLINE DRAWING
CXC 125/220VDC
...
...
1:3
PER P.O. and
Doc. 070-024-83
2 3
EOF
J.U.
2003/06
2004/08
D2
c 2003 ARGUS TECHNOLOGIES O
A
DIMENSIONS ARE IN INCHES WITH METRIC [mm] IN BRACKETS: INCHES [mm]
