Alpha Technologies Te41, 48V - Manual (Page 40)

1
1
2
2
3
3
4
4
5
5
6
6
D D
C C
B B
A A
2 11
SCHEMATIC, 48V ENCLOSURE W/
747-654-05 P/A
2009/07/08
12:28:06 PM
74765405PA_SHEET2.SCHDOC
Title
SIZE DWG NO.
Date:
File:
Rev
Sheet of
Time:
B
22kAIC AC PANEL, FAN DOOR,
V3 DUAL COMPARTMENT
THESE DESIGNS AND SPECIFICATIONS ARE THE PROPERTY OF
ARGUS TECHNOLOGIES AND SHALL NOT BE COPIED OR USED
FOR MANUFACTURING WITHOUT ITS WRITTEN CONSENT.
TYPE
ISSUE
DATE
REVISION
LTR DESCRIPTION DATE APPD
S5
4000 BTU/Hr
RETURN AIR
SUPPLY AIR
LINE
NEU
AC INPUT
GND
AIR CONDITIONER UNIT
120VAC, 60Hz
POWER
GRN
WHT
BLK
15A/125V
BONDING
SCREW
J3
J4
GRN
HOT 'WHT'
GND
GFCI CONVENIENCE OUTLET
TEST
RESET
LINE
NEU
TERMINALS
BONDING
SCREW
BLK - #14 AWG
WHT - #14 AWG
GRN - #14 AWG
BLK - #14 AWG
WHT - #14 AWG
GRN - #14 AWG
2 3 1
1 2 3
N.O.
COM
STATUS ALARM
N.C.
OUTPUT
N.O.
COM
ON ALARM WIRING TERMINAL BLOCKS
(REFER TO SHEET 5)
TO TB37
TO TB38
59
60
BRN - #16 AWG
BLU - #16 AWG
GRN - #16 AWG
YEL - #18 AWG
RED - #18 AWG
BLU - #18 AWG
J2
P2
EQUIPMENT AC POWER DISTRIBUTION WIRING:
MOLEX
CONNECTOR
BLK GRN
GRN BRN
ORG
ORG
WHT
YEL
GRN
LOWER COMPARTMENT
'UTILITY BOX'
'UTILITY BOX' NOTES:
1.) USE 14/3 SJ FLEXIBLE CORD FOR WIRING UNLESS OTHERWISE INDICATED.
YEL
47
45
43
(REFER TO SHEET 1)
FROM AC PANEL
LINE
NEU
GND
BLU
(REFER TO SHEET 1)
FROM AC PANEL
LINE
NEU
GND
48
46
44
NOTE
DEFAULT SETPOINTS:
A/C: 27C (80F)
HEATER: 16C (60F)
N.C. LEAVE BLUE WIRE
UNTERMINATED
AT TERMINAL BLOCK
YEL - #18 AWG
RED - #18 AWG
BLU - #18 AWG
