How to install optional reflectors – Alera Lighting SLS User Manual
Page 4
S
OLARIS
T
ECHNICAL
I
NSTALLATION
D
ATA
I
NST
ALLA
TION
I
NSTR
UCTIONS
Step 1
• Wedge reflector into top of
louver.
• Reflector will be a little longer
than louver. Reflector should
slightly overhang onto socket
pan.
How to Install Optional Reflectors
(85/15 reflector)
Finished Appearance (Top View)
Finished Appearance (Bottom View)
Step 2
• Push down the length of the
reflector so it snaps into louver.
• Reflector should be sitting
snugly on top of louver baffles.
13-1.2
C
AL 09/07
701 Millennium Blvd
Greenville SC 29607 • (864) 678-1000
www.aleralighting.com
We are architectural fluorescent lighting
Subject to change without notice.
