1.2c, How to install optional reflectors – Alera Lighting SLS User Manual
Page 3
I
NST
ALLA
TION
I
NSTR
UCTIONS
S
OLARIS
I
NSTALLATION
D
ATA
Step 1
• Squeeze end of reflector in.
• Lodge one end of reflector into
top of louver.
How to Install Optional Reflectors
(For 0/100, 20/80 and 40/60 reflectors)
Finished Appearance (Top View)
Finished Appearance (Bottom View)
Step 2
• Press reflector down to where it
hits top of baffles.
• Continue down louver until
entire reflector is lodged in
louver.
13-1.2
C
701 Millennium Blvd
Greenville SC 29607 • (864) 678-1000
www.aleralighting.com
We are architectural fluorescent lighting
Subject to change without notice.
