Technical data – ABUS TVHD50000 User Manual
Page 34
34
11. Technical
data
TVHD50000 TVHD50500
Image sensor
1/2.8" progressive scan Sony Exmore CMOS
DSP
Sony IT-N
Camera type
HD-SDI standard camera
Resolution
1080p
Pixels (total)
2000 x 1241
Pixels (effective)
1920 x 1080
Lens mount
CS, C
Lens control
AI
Day/night switching
IR swivel filter (ICR), color / B/W
Minimum illumination
(color)
1 lux @ F1.2
Minimum illumination
(IR)
0 lux @ F1.2
Noise reduction
2D DNR
Electronic shutter
Rolling shutter
White balance
AWB, 1800~10000K
Gain control
Auto
Backlight compensation
Soft WDR
Dynamic range (WDR)
50 dB
Video system
SMPTE292M (HD-SDI)
Synchronization
Internal
Privacy masking zones
16 freely-configurable masks
Back focus adjustment
Yes
Connections
1 x BNC (HD-SDI),
1 x BNC (FBAS, 1Vss, 75 Ohm),
1 x DC (5.5x2.1mm)
Power supply
12 V DC, 24 V AC
110–240 V AC
Power consumption
500 mA (max.)
Operating temperature
-10°C ~ +50 °C
Humidity
0-85% non-condensing
Protection class
IP34
Dimensions (W x H x D)
69 x 59 x 122 mm
Weight
420 g
Certifications
CE, RoHS, REACH
