Status LEDs
Description of symbols:
●
LED active
○
LED deactive
DIP switch 2 off (
↓ )
Resolution SD LED HD LED 3G LED POWER LED
1280 x 720 p50
○ ○ ● ●
1280 x 720 p60
○ ● ○ ○
1920 x 1080 i50
○ ● ○ ●
1920 x 1080 i60
○ ● ● ○
1920 x 1080 p24
○ ● ● ●
1920 x 1080 p25
● ○ ○ ○
1920 x 1080 p30
● ○ ○ ●
1920 x 1080 p50
● ○ ● ○
1920 x 1080 p60
● ○ ● ●
2048 x 1080 p24
● ● ○ ○
2048 x 1080 p25
● ● ○ ●
Not supported
● ● ● ●
DIP switch 2 on (
↑ )
Resolution 3G LED HD LED SD LED
Not supported
○ ○ ●
720p, 1080i, 1080 [p24,
p25]
○ ● ○
1080 [p50, p60], 2K
● ○ ○
