31
English
7.4 Connect the monitor to a HD-SDI via coaxial cable.
Use a coaxial cable (RG6) with BNC plugs (male) for the connection.
7.5 Only now connect the supplied power supply with the monitor and a 230VAC power socket.
8. Selecting the input signal
To select the input signal, press the source button.
The selected input will be displayed on the upper left of the screen.
Press the Source button repeatedly until you reach the required input and confirm the entry with the + or
- button.
You have the choice of HDMI, VGA, SDI, AV1, AV2 and S-Video.
