14
English
1. Intended use
This 12 – 15 VDC high-performance transformer offers you a stabilized central power supply for cameras
and IR illuminators. Because of its protection class IP66 it is also suitable for outdoor usage.
A detailed description of all functions can be found in chapter „3 Features and functions“.
2. Scope of delivery
• High-performance
transformer
• Installation
instructions
• 2 x high-strength cable gland
3. Features and functions
• 12 - 15 VDC / 5 A power supply unit for outdoor use
• Electronic overload protection
• Protection class: IP66
4. Overview – type numbers
Article number TVAC35600
Input voltage 230 VAC
Output voltage 12 - 15 VDC
Output current 5 A
5. Installation
This device is designed for a fixed indoor or outdoor installation. Allow at least 100 mm between this
device and other equipment. Use the holes on the sides for cable feed.
5.1 Installation high-strength cable glands
Use a suitable tool for punching out the mounting holes (called M20) and fit a high-strength cable gland
with its rubber ring.
Please note:
You must use the 2 glands for cable entry to guarantee the IP66 rating of the installation.
