ABUS SG1683 Flashing light and siren User Manual
Page 6
5
Electrical connections
See the technical data of this equipment. Fig. 2 shows the
wiring diagram for connecting the equipment:
(1) White: 9–12 V DC, flashlight
(2) Red:
9–12 V DC, flashlight + siren
(3) Brown: Ground
This equipment is designed for operation with alarm
systems only. Before installing, read the operating
instructions of your alarm system.
Before connecting this equipment, make sure that
the power supply is switched off in all power lines.
Maintenance
Check the technical safety of this equipment regularly by
making appearance and function checks.
Cleaning
Clean the device only with a dry, lint-free cloth. Do not use
any cleaning solvents!
Disposal
Dispose of old/used equipment only according to current legal
regulations.
Technical data
Operating voltage
9–12 V DC
Power consumption ca. 200 mA
Sound pressure
ca. 100 dB/1 m
Order numbers:
red:
SG1681
Yellow:
SG1682
Blue:
SG1683
