Appendix C Standard Firewall Platform Setting

C-2

C.1 Standard Firewall Platform Setting

Disable

I/O PORT 48Fh set bit 4 to 1,

I/O PORT 4B8h set bit 3 to 1

Red LED ON

I/O PORT 48Fh set bit 4 to 1,

I/O PORT 4B8h set bit 3 to 0

Red LED Blink

I/O PORT 48Fh set bit 4 to 1,

I/O PORT 4B8h set bit 3 to 0

I/O PORT 49Bh set bit 4 to 1

Green LED ON

I/O PORT 48Fh set bit 4 to 0,

I/O PORT 4B8h set bit 3 to 1

Status LED

Green LED Blink I/O PORT 48Fh set bit 4 to 0,

I/O PORT 4B8h set bit 3 to 1

I/O PORT 49Bh set bit 4 to 1

Disable

I/O PORT 48Dh set bit 7 to 1,

I/O PORT 48Fh set bit 2 to 0

Force Mode

I/O PORT 48Dh set bit 7 to 0,

I/O PORT 48Fh set bit 2 to 0

LAN Bypass

Watch Dog Mode I/O PORT 48Dh set bit 7 to 1,

I/O PORT 48Fh set bit 2 to 1

Disable

LCM Function

378/IRQ7

Software Reset

Press Software Reset button I/O PORT:

4B8h bit 6 will be set 1
