Chapter 2 Quick Installation Guide 2-9
2.10 USB Connector (USB1)
Pin Signal Pin Signal
1 GND 2 XUSBD4+
3 XUSBD4- 4 +5V
5 GND 6 XUSBD5+
7 XUSBD5- 8 +5V
Note: When activating the COM port LL5 test, please “Disable” the USB
keyboard and mouse in BIOS setting.
2.11 USB Pin Header (CN4, CN5)
Pin Signal Pin Signal
1 +5V 2 GND
3 USBD- 4 GND
5 USBD+ 6 USBD+
7 GND 8 USBD-
9 GND 10 +5V
2.12 RS-232 Serial Port Connector (COM1/2)
Pin Signal Pin Signal
1 DCD 2 RXD
3 TXD 4 DTR
5 GND 6 DSR
