Chapter 2 Quick Installation Guide
2-13
5 LAFD-
6 LINIT-
7 LPD1
8 LPD0
9 LPD3
10
LPD2
11 LPD5
12 LPD4
13 LPD7
14 LPD6
15 LCD-
16 VCC
17 UP
18 RIGHT
19 LEFT
20 DOWN
21 RESET
22 NC
23 NC
24 NC
2.21 Power Connector for PCI-X Riser (CN8)
Pin Signal
Pin Signal
1 GND
2 +3.3V
3 +3.3V
4 +3.3V
5 -12V
6 +5V
7 +5V
8 GND
