N e tw o r k A p p l i a n c e F W S - 8 1 6 B
Chapter 2 Quick Installation Guide 2-8
2.7 Clear CMOS (JP1)
JP1 Function
1-2 Clear
Open Protected (Default)
2.8 Front Panel Connector (FP1)
Pin Signal Pin Signal
1 Power On Button (+) 2 Reset Switch (+)
3 Power On Button (-) 4 Reset Switch (-)
5 IDE LED (+) 6 Power LED (+)
7 IDE LED (-) 8 Power LED (-)
2.9 Front Panel Connector (FP2)
Pin Signal Pin Signal
1 External Speaker (+) 2 NC
3 NC 4 NC
5 Internal Buzzer (-) 6 I2C Bus SMB Clock
7 External Speaker (-) 8 I2C Bus SMB Data
Note: Internal Buzzer enable: Close Pin 5,7
