N e tw o r k A p p l i a n c e F W S - 8 1 6 B
Chapter 2 Quick Installation Guide 2-28
Step 5: Insert the Add-on card to the FWS-816B
Round silver
mark
L Shape
indentation
Note: There is a round silver mark on the top of the front panel. Please
make sure the L shape indentation on the cover has been aimed at
the mark when you insert the card to the FWS-816B.
Step 6: When the Add-on Card has been inserted to the expansion
slot properly, slide it horizontally to the opposite direction
mentioned in Step 1 and you have finished the Add-on Card
Installation
