E m b e d d e d B o x T K S - P 2 0 - C V 0 1
Chapter 2 Quick Installation Guide 2-9
2.5 List of Jumpers
The board has a number of jumpers that allow you to configure your
system to suit your application.
The table below shows the function of each of the board's jumpers:
Label Function
JP1 COM2 RI/+5/+12V Selection
JP2 Clear CMOS
JP6 AT/ATX Power Mode Selection
2.6 List of Connectors
The board has a number of connectors that allow you to configure your
system to suit your application. The table below shows the function of
each board's connectors:
Label Function
CN1 COM Port 1
CN2 COM Port 2
CN3 Digital I/O
CN4 +5V Output for SATA HDD
CN5 SATA Port
CN7 RJ-45 Ethernet
CN10 LPC Expansion I/F
CN11 USB Port 5
CN12 Analog CRT Display
CN13 USB Port 3
CN14 USB Port 4
CN16 USB Port 1 and 2
