AAEON TKS-P20-CV01 User Manual
Page 19

E m b e d d e d B o x
T K S - P 2 0 - C V 0 1
Chapter 2 Quick Installation Guide
2-4
2.3 A Quick Tour of the TKS-P20-CV01
Before you start to set up the TKS-P20-CV01, take a moment to
become familiar with the locations and purposes of the controls, drives,
connections and ports, which are illustrated in the figures below.
When you place the TKS-P20-CV01 upright on the desktop, its front
panel appears as Show in Figure 2-1.
Front View
Front View of the Point of Care Terminal
(1)
(8)
(6)
(7)
(2)
(3)
(4)
(5)
(1). Power and HDD indicator LED
(2). Gigabit Ethernet LAN Port
(3). VGA port
(4). USB x2
(5). Mini HDMI port
