E m b e d d e d B o x T K S - P 2 0 - C V 0 1
Chapter 1 General Information 1- 4
1.3 Specifications
CPU
Onboard Intel
®
Atom™ N2600
Processor up to 1.6 GHz
Chipset Intel
®
Atom™ N2600 + NM10
System Memory
204-pin DDR3 SODIMM x 1, Max.
2GB
VGA D-SUB 15 x 1 Display
Interface HDMI HDMI type C (Mini HDMI) x 1
SSD mSATA x 1 (Half-size) Storage
Device HDD Optional by request
LAN Gigabit Ethernet
Network
Wireless Optional by Mini Card
USB Host USB 2.0 x 2
LAN RJ-45 x 1
Serial Port RS-232 x 1, RS-232/422/485 x 1
Front I/O
Others
System & HDD indicator LED x 2,
Power Switch, DC-in
DIO DIO 4-bit with VCC and ground in
Rear I/O
Audio Mic-in/ Line-out
Bottom I/O USB Host USB2.0 x 3
Expansion Mini PCIe Mini Card half size (or mSATA)
Indicator Front Power LED x 1, HDD LED x 1
Power Requirement
DC-in +12V ATX or DC-in +7~30V
ATX (Optional)
Power Consumption
Intel
®
Atom™ N2600 1.6 GHz, DDR3
800 2GB, 1.5A @ +12V
