EMB-H81A 1-2
1.3 Specifications
SYSTEM
Form factor Mini-ITX
CPU LGA1150 socket for Intel ® 4 th Generation Core™ i7 / Core™ i5 /
Core™ i3, Pentium ® / Celeron ® processors
Supports Intel ® CPU up to 65W
Memory 2 x SO-DIMM (8GB per DIMM), max. 16GB, non-ECC DDR3 1600
/ 1333 MHz
Dual-channel memory architecture
Chipset Intel ® H81 Express Chipset
I/O Chipset NCT6791D & NCT5104D
Ethernet 2 x Realtek ® 8111F PCIe Gigabit LAN
BIOS 64Mbit Flash ROM, AMI BIOS
Wake on LAN Yes (WOL/PXE)
Watchdog Timer 1~255 steps by software program
TPM Infineon SLB9635 TT 1.2
H/W Status Monitor Monitors CPU/Chassis temperature
Monitors Vcore/5V/3.3V/12V voltages
Monitors CPU/Chassis fan speed
Smart Fan Control CPU Fan/Chassis Fan
Power State S3, S4, S5
Expansion slot 1 x PCI Express 2.0 x4 slot
1 x Full/Half-size Mini Card (USB+PCIe) with mSATA option (with
SATA 6Gb/s)
Battery
Lithium battery
Power requirement 1 x 24-pin ATX connector
1 x 4-pin ATX 12V power connector
Board size
6.7 in. x 6.7 in. (17.0 cm x 17.0 cm)
Gross weight
1.1 lb (0.5 Kg)
Operating
temperature
32 o F~140 o F (0 o C~60 o C)
Storage temperature
-40 o F~185 o F (-40 o C~85 o C)
Operating humidity
0%~90% relative humidity, non-condensing
Power compliance
Compliant with Eup/ErP
Certificate
CE/FCC
(continued on the next page)
