AAEON EMB-H81A User Manual
Page 11
2-3
Chapter 2: Motherboard information
Connectors/Jumpers/Slots
Page
1.
COM1 Ring/+5V/+12V selection (COM1_V1)
2-14
2.
ATX power connectors (24-pin EATXPWR, 4-pin EATX12V)
2-19
3.
CPU and system fan connectors (4-pin CPU_FAN1, 4-pin CHA_FAN1)
2-20
4.
Intel
®
LGA1150 CPU socket
2-6
5.
DDR3 SODIMM slots
2-11
6.
Inverter Back Light Control mode selection (3-pin J3)
2-15
7.
LPT connector (26-1 pin LPT1)
2-25
8.
Serial port connectors (10-1 pin COM3 ~ COM6)
2-25
9.
Digital I/O connector (10-pin DIO1)
2-20
10. Clear RTC RAM (CLRTC)
2-13
11. System panel connector (10-1 pin F_PANEL)
2-22
12. Minicard connector (MINICARD)
2-24
13. Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1, SATA3G_2)
2-23
14. Serial ATA 6.0Gb/s connectors (7-pin SATA6G_1, SATA6G_2)
2-23
15. Standby Power LED (SB_PWR LED1) (SB_PWR LED1)
2-16
16. USB 2.0 connector (10-1 pin USB45, USB10)
2-24
17. LVDS panel voltage selection (3-pin J1)
2-14
18. Inverter voltage selection (3-pin J2)
2-15
19. LVDS connector (30-pin LVDS1)
2-21
20. Front panel audio connector (10-1 pin AAFP1)
2-21
21. Backlight inverter power connector (5-pin INV1)
2-22
