EMB-H81A 2-2
EATX_PWR2 EATX_PWR1
COM1_V1
ALC
887
AAFP1 LVDS1
Super
I/O
MINICARD
CLRTC
J3
17.0cm(6.7in)
17.0cm(6.7in)
DDR3_SO-DIMM_A1 (64bit, 204-pin module)
Intel ®
H81
DDR3_SO-DIMM_B1 (64bit, 204-pin module)
SATA6G_1 SATA6G_2
SATA3G_3 SATA3G_4
KBMS_USB89
AUDIO1
LAN1_USB3_1
LAN2_USB34
F_PANEL
J2
J1
LED1
LED2
BZ1
USB45
USB10
CPU_FAN1
CHA_FAN1
COM6
COM5
COM3
COM4
DIO1
LGA1150
PCIEX4_1
LPT1
INV1
BATTERY
RTL
8111F
CHRONTEL
CH7511B
ASM
1442
RTL
8111F
ANX
988
Nuvoton
NCT5104D
DVI_I VGA1
COM2 COM1
3 4 5 2 1 2 3
8
9
10
11
6
7
19 12 13
20
14 15 16 17 18
21
2.2 Motherboard layout
Place this side
towards the rear
of the chassis
NOTE: Place four screws into the holes indicated by circles to secure the
motherboard to the chassis.
CAUTION! Do not overtighten the screws! Doing so can damage the
motherboard.
