2-17 Chapter 2: Motherboard information
LAN port
Speed
LED
Activity Link
LED
ACT/LINK LED SPEED LED
Status Description Status Description
OFF No link OFF 10 Mbps
connection
ORANGE Linked ORANGE 100 Mbps
connection
BLINKING Data activity GREEN 1 Gbps
connection
3. LAN1~2 (RJ-45) port. These ports allow Gigabit connection to a Local Area
Network (LAN) through a network hub. Refer to the table below for the LAN1
port LED indications.
LAN1 port LED indications
4. Line In port (light blue). This port connects the tape, CD, DVD player, or
other audio sources.
5. Line Out port (lime). This port connects to a headphone or a speaker. In a
4-channel, 6-channel and 8-channel configurations, the function of this port
becomes Front Speaker Out.
6. Microphone port (pink). This port connects a microphone.
NOTE: Refer to the audio configuration table below for the function of the
audio ports in the 2.1, 4.1 or 5.1-channel configuration.
