AAEON PCM-QM77 User Manual
Page 64
C o m p a c t B o a r d
P C M - Q M 7 7
Chapter 2 Quick Installation Guide
2-49
5 USB1_SSTX−
DIFF
6 USB1_SSTX+ DIFF
7 GND GND
8 USB1_D- DIFF
9 USB1_D+ DIFF
10 NC
11
USB2_D+ DIFF
12
USB2_D- DIFF
13
GND GND
14 USB2_SSTX+
DIFF
15 USB2_SSTX−
DIFF
16 GND
GND
17 USB2_SSRX+
DIFF
18 USB2_SSRX−
DIFF
19 +5VSB PWR
+5V
