C o m p a c t B o a r d P C M - Q M 7 7
Chapter 1 General Information 1-2
1.1 Introduction
The PCM-QM77 supports Intel
®
3rd Generation Intel
®
Core™
i7/i5/i3/Celeron
®
processor which when paired with the Intel
®
QM77/HM76 chipset offers a high performance computing
platform with low power consumption. This new product
supports two DDR3/L SODIMMs at speed of 1333/1600 MHz,
up to 16 GB. One CFast™ and two SATA 6.0Gb/s (Optional
RAID) interfaces provide ample storages. With dual Gigabit
Ethernet, ten COM ports, four USB3.0 and four USB2.0, the
PCM-QM77 meets the requirements of today’s demanding
applications.
Display requirements are met with an abundance of interfaces
such as VGA, DVI, and LVDS. The graphic engine adopts 3
rd
generation Intel
®
QM77/HM76 to offer high definition display
function. In addition, it supports up to two 24-bit Dual-Channel
LVDS, and one DVI.
With all of its integrated features, the PCM-QM77 strikes a
balance of performance and price. This versatile product targets
Industrial Automation, Entertainment, Networking, KIOSK/POS,
Transportation, Banking, Healthcare and Digital Signage
applications that require high performance and high reliability.
