C o m p a c t B o a r d P C M - Q M 7 7
Chapter 1 General Information 1-4
1.3 Specifications
System
 From Factor 5.25” Compact Board (203 mm x
146 mm)
 Processor Intel
®
3rd Generation Intel
®
Core
™
i7/i5/i3/Celeron
®
processor
 System Memory 204-pin DDR3 SODIMM x 2,
DDR3/L 1333/1600, up to 16GB
 Chipset Intel
®
QM77/HM76
 Ethernet Intel 82579LM Gigabit PHY x1 &
Intel 82583V Gigabit x 1, RJ-45 x
2 co-lay with pin header Intel
82583V co-lay with Intel 82574L
Support IEEE1588
 BIOS Plug & Play BIOS – 16MB flash
 Wake On LAN Yes
 Watchdog Timer Generates a time-out system
reset
 H/W Status
Monitoring Supports power supply voltages
and temperature monitoring
 Expansion Interface Mini Card x1, mSATAx1, PCI x1
and PCI Express [x16] x1
 Battery Lithium Battery
 Power Requirement ATX/AT AT mode to control by
jumper, and BIOS need to be set
ACPI disabled
 Board Size 8”(L) x5.75” (W) (203mm x
146mm)
 Gross Weight 0.88 lb (0.4Kg)
