VSC 150 • Specifications

VSC 150 • Specifications

Specifications, cont’d

A-3

Specifications

A-2

Video input

Number/signal type ................... 1 VGA, 1 Mac analog RGBHV, RGBS,

RGsB

Connectors .................................... VGA ........... 15-pin HD female

Mac ............ 15-pin D female

Minimum/maximum level(s) .... Analog ....... 0V to 2.0V p-p with no offset
Impedance .................................... 75 ohms or High Z (DIP switch-selectable)
Horizontal frequency .................. Autoscan 24 kHz to 71 kHz
Vertical frequency ....................... Autoscan 50 Hz to 120 Hz
Resolution range .......................... Autoscan 560 x 384 to 1280 x 1024

Note: 1280 x 1024 is available at 60 Hz
only.

External sync (genlock) ............... 0.3V to 1.0V p-p

The color subcarrier adjustment range is ±90° from 0° for a total
adjustment range of 180°.

Video processing

Encoder ......................................... 10 bit digital
Digital sampling .......................... 24 bit, 8 bits per color; 50 MHz standard
Colors ............................................ 16.8 million
Horizontal filtering ...................... 2 levels (selectable)
Vertical filtering ........................... 3 levels (selectable)
Encoder filtering .......................... 3 levels (selectable)

Video output

Number/signal type ................... 1 RGBHV/RGBS ...... 15.75 kHz analog, or

1 component video, or
1 S-video .... NTSC, 15.75 kHz, 525 lines, or

PAL, 15.5 kHz, 625 lines

1 composite video ....

NTSC, 15.75 kHz, 525 lines, or
PAL, 15.5 kHz, 625 lines

Connectors .................................... RGBHV/RGBS ......... 6 BNC female

S-video ....... 1 4-pin mini-DIN female
Component video (YUV) .......

3 BNC female
(uses the R, G, and B BNCs)

Composite video ...... 1 BNC female

Nominal level ............................... RGBHV/RGBS, component .. 0.7V p-p

S-video, composite video ...... 1.0V p-p

Impedance .................................... 75 ohms

Sync

Input type ..................................... Autodetect RGBHV, RGBS, RGsB
Output type .................................. RGBHV, RGBS
Genlock connectors ..................... 2 BNC female
Standards ...................................... NTSC 3.58, PAL
Input level ..................................... 1.5V to 5.0V p-p
Output level .................................. TTL ............. 5.0V p-p
Input impedance .......................... 75 ohms
Output impedance ....................... 75 ohms
Polarity .......................................... Negative

Control/remote — scan converter

Serial control port ........................ RS-232, 9-pin female D connector
Baud rate and protocol ............... 9600, 8-bit, 1 stop bit, no parity
Serial control pin configurations . 2 = TX, 3 = RX, 5 = GND
IR controller module ................... Extron’s IR 601
Program control ........................... Extron’s control program for Windows®

Extron’s Simple Instruction Set™ – SIS™

General

Power ............................................. 100VAC to 240VAC, 50/60 Hz, 40 watts,

internal, auto-switchable

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /

10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing

Rack mount ................................... Yes, with optional rack shelf,

part #60-190-01

Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 8.75" W x 9.50" D

4.45 cm H x 22.23 cm W x 24.13 cm D
(Add 0.5” for front panel knobs and
0.75” for rear panel connectors.)

Shipping weight ........................... 5 lbs (2.3 kg)
Vibration ....................................... ISTA/NSTA 1A in carton

(International Safe Transit Association)

Approvals ..................................... UL, CUL, CE, FCC Class A
MTBF ............................................. 30,000 hours
Warranty ....................................... 2 years parts and labor

Specifications are subject to change without notice.
