CMRR ............................................ >75dB @ 20 Hz to 20 kHz
Audio input
Number/signal type ................... 1 stereo, unbalanced
Connectors ................................... 1 3.5 mm female stereo jack, 2-channel; tip
(L), ring (R), sleeve (GND)
Impedance .................................... >5 kohms unbalanced, DC coupled
Maximum level ............................ +8.5dBu (unbalanced
Audio output
Number/signal type ................... 1 stereo, balanced/unbalanced
Connectors ................................... 1 3.5 mm captive screw connector, 5 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Maximum level (Hi-Z) ................ >+14dBu, balanced or unbalanced at stated
%THD+N
Maximum level (600 ohm) ......... >+0dBu, balanced or unbalanced at stated
%THD+N
0dBu = 0.775 volts (RMS).
General
Power ............................................ 100VAC to 240VAC , 50/60 Hz, 5 watts,
external, autoswitchable; to 9VDC, 1A
power supply.
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount .................................. No
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.0" H x 5.7" W x 4.5" D
2.5 cm H x 14.5 cm W x 11.4 cm D
Product weight ............................. 0.6 lbs (0.3 kg)
Shipping weight ........................... 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
