PCA Part numbers
Item
Part number
PCA 100, Pipe Coupling Adapter, FF, black or white
70-604-02, -03
Projector mounting accessories
Item
Part number
PMP 24, Projector Mounting Pole, 24", black or white
70-511-62, -63
PMP 18, Projector Mounting Pole, 18", black or white
70-511-42, -43
PMP 12, Projector Mounting Pole, 12", black or white
70-511-32, -33
PMP 10, Projector Mounting Pole, 10", black or white
70-511-22, -23
PMP 6, Projector Mounting Pole, 6", black or white
70-511-12, -13
PMP 4, Projector Mounting Pole, 4", black or white
70-511-02, -03
PMP 2, Projector Mounting Pole, 2", black or white
70-511-52, -53
FCMP 1010, Flat Ceiling Mounting Plate, 10", black
70-585-02
FCMP 44, Flat Ceiling Mounting Plate, 4", black
70-504-02
ACMP 100, Angled Ceiling Mounting Plate, black
70-503-02
PCM 240, Projector Drop Ceiling Mount, white
60-772-03
PMK 350, Low Profile Projector Mounting Kit, black or white
70-563-02, -03
UPB 25, Universal Projector Mount, black or white
60-773-02, -03
Security Screws Kit, UPB 25
70-555-01
Installation Notes, cont'd
Extron
UPB 25
Universal Projector
Mounting Bracket
Extron
PCM 240
Projector Drop
Ceiling Mount
Extron
PMK 350
Above Projector
Mount Bracket
Extron
Power Supply
for MPA 122
Projector
Extron
PMP
6", 10", 12",18",
or 24"
Projector Mount
Pole
BA
SS
LE
VE
L
TR
EB
LE
MIN
I P
OW
ER
AM
PL
IFIE
R
MP
A 12
2
ON
OFF
LIMI
TER
STE
REO
DUA
L
MO
NO
Extron
MPA 122
Mini Power
Amplifier
Figure 2 — A typical projector mounting installation, using an Extron
PCM 240, a PMK 350, a PMP, and a UPB 25 Universal Projector Mounting Bracket
