A-5 CrossPoint Plus Matrix Switchers • Specifications
Optional accessories
Extron Part Part #
Rack/desk mounting kit 70-077-03
MKP 1000
Gray 60-239-01
Black 60-239-02
White 60-239-03
MCP 1000M (master) 60-298-01
MCP 1000S (slave) 60-298-02
Captive screw audio connector 10-319-10
RCA-to-BNC adapter 10-264-01
SVHS - BNC adapter 26-353-01
Cables
When using signals with a scanning frequency of 15-125 kHz and running distances
of 100 feet or more, use high resolution BNC cables to achieve maximum
performance.
Bulk cable
Extron Part Part #
RG6 super high resolution cable
RG6-1 bulk , 500’
22-098-02
RG6-1 bulk , 1000’ 22-098-03
RG6-4 bulk , 500’ 22-099-02
RG6-5 bulk , 500’ 22-100-02
RG6 male crimp connectors, qty. 50 100-075-51
BNC-4 Mini HR Cable
BNC-4 Mini HR bulk, 500’
22-032-02
BNC-4 Mini HR bulk, 1000’ 22-032-03
BNC-5 Mini HR Cable
BNC-5 Mini HR bulk, 500’
22-020-02
BNC-5 Mini HR bulk, 1000’ 22-020-03
Plenum BNC-5 Mini HR Cable
Plenum BNC-5 Mini HR bulk, 500’
22-103-02
Plenum BNC-5 Mini HR bulk, 1000’ 22-103-03
Assorted connectors
BNC connectors
BNC Mini HR crimp connectors, qty. 50
100-074-51
RG6 male crimp connectors, qty. 50 100-075-51
BNC bulkhead connectors, qty. 50
(for custom wall plates) 100-076-51
